Residential Energy Storage System
SK-5K5LV / SK-6K10LV
5kW/5kWh
Type-C, USB, Plug & play, Wheels, LED screen, Fast Charge
5kWh Plug & Play UPS LiFePO4 Portable Power Generator | SmartKab
Discover SmartKab 5kWh Plug & Play UPS. Featuring long-lasting LiFePO4 battery technology, this portable power generator provides 5kWh reliable backup for home, RV, and emergency use. Zero installation, easy mobility with wheels, and solar-ready. Power your life anytime, anywhere. Shop now for sustainable energy solutions!
Product Parameters
Rated Power5000VA/5000W
Surge Power10000VA
Nominal Voltage230VAC
Selectable Voltage Range (PC)170-280VAC
Selectable Voltage Range (Appliances)90-280VAC
Nominal Frequency50/60Hz (Auto Sensing)
Nominal Voltage230VAC (Settable)
Frequency50/60Hz
WaveformPure Sine Wave
Transfer Time (UPS)10ms
Transfer Time (Appliances)20ms
Overload Protection @ 105%~110% Load60s
Overload Protection @ 110%~140% Load10s
Overload Protection @ ≥140% Load5s
Battery TypeLiFePO4
Battery Voltage51.2VDC
Capacity100Ah
Battery Voltage Range42~58.4V
Lithium Battery ActivationYES (By PV or Utility)
Solar Charger TypeMPPT
Maximum PV Array Power5500W
Maximum PV Array Open Circuit Voltage500VDC
MPPT Operating Voltage Range60VDC~450VDC
Maximum PV Input Current27A
Maximum Solar Charge Current100A
Maximum AC Charge Current30A/100A
Maximum Charge Current (PV+AC)100A
Peak Efficiency (PV to INV)96%
Peak Efficiency (Battery to INV)93%
Product Dimension (D×W×H)450×280×705mm
Packing Dimension (D×W×H)535×365×765mm
Net Weight60kg
Communication InterfaceRS232/RS485(BMS)/Bluetooth/WiFi
Parallel CapacityYES
Type of PV ConnectionMC4
Type of AC Input ConnectionIEC C14 Inlet/Circular Connector
Type of Battery Expansion ConnectionCircular Connector (Optional)
Type of AC Output Connection30A Circular Connector×1, 10A CN/13A UK/16A EU Socket×3
Type of DC Output ConnectionUSB: 18W×4, Type C: 100W×1, 60W×1, DC: 12V10A×1, 12V5A×2
Operating Temperature Range (Charge)0℃~50℃
Operating Temperature Range (Discharge)-10℃~50℃
Storage Temperature-20℃~25℃
Humidity5%~95% Relative Humidity (Non-condensing)
